1. Power Supply: 15–30 VDC loop-powered two-wire system
2. Output Signal: 4–20mA linear current signal proportional to vibration velocity
3. Model Suffix Definition:
– 4: Measuring range 0–20 mm/s (0–0.8 IPS) vibration velocity
– R1: RMS signal output, frequency response 10–1000Hz (600–60000 CPM)
– 1E: Top exit 2-pin MIL-C-5015 male connector interface
4. Stable warm-up time: ≤30 seconds
5. Full-scale error: ±10% FS
6. Galvanic isolation between shell and internal circuit: >10 MΩ
Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E Specifications
| 1. Power Supply | 15–30 VDC loop-powered two-wire system |
|---|---|
| 2. Output Signal | 4–20mA linear current signal proportional to vibration velocity |
| R1 | RMS signal output, frequency response 10–1000Hz (600–60000 CPM) |
| 1E | Top exit 2-pin MIL-C-5015 male connector interface |
| 4. Stable warm-up time | ≤30 seconds |
| 5. Full-scale error | ±10% FS |
About the Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E
The Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E is a instrumentation used in industrial automation, control and power systems. It is rated at 1. Power Supply 15–30 VDC loop-powered two-wire system, 2. Output Signal 4–20mA linear current signal proportional to vibration velocity, R1 RMS signal output, frequency response 10–1000Hz (600–60000 CPM). This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E for accurate procurement and cross-referencing.
Why source the Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E from HDE123
- Verified part number: every Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E is checked against its manufacturer specification before shipment.
- 6 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E
To order the Series Loop-Powered Vibration Velocity Transmitter Sensor М8/LP202-4R1-1E, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
