Product Name: Pressure Transmitter
Model: A-10
Part Number:12719332
Measuring Range: 0~250 bar (Gauge pressure)
Output: 4~20mA, 2-wire
Supply Voltage: 8~30 V DC
Accuracy: ±0.5% BFSL
Process connection: G1/4 A DIN3852-E, NBR seal
Electrical connection: DIN 4-pin L-type connector
Wetted material: 316L stainless steel
Operating temperature: 0 ~ +80℃
Protection: IP65
12719332 - Model A-10 Specifications
| Product Name | Pressure Transmitter |
|---|---|
| Model | A-10 |
| Part Number | 12719332 |
| Measuring Range | 0~250 bar (Gauge pressure) |
| Output | 4~20mA, 2-wire |
| Supply Voltage | 8~30 V DC |
| Accuracy | ±0.5% BFSL |
| Process connection | G1/4 A DIN3852-E, NBR seal |
| Electrical connection | DIN 4-pin L-type connector |
| Wetted material | 316L stainless steel |
| Operating temperature | 0 ~ +80℃ |
| Protection | IP65 |
About the 12719332 - Model A-10
The 12719332 - Model A-10 is a instrumentation used in industrial automation, control and power systems. It is rated at Product Name Pressure Transmitter, Model A-10, Part Number 12719332. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 12719332 - Model A-10 for accurate procurement and cross-referencing.
Why source the 12719332 - Model A-10 from HDE123
- Verified part number: every 12719332 - Model A-10 is checked against its manufacturer specification before shipment.
- 12 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 12719332 - Model A-10
To order the 12719332 - Model A-10, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
