1. Coil parameters:
Rated coil voltage: * * 110 V DC**
Coil resistance: * * 26.6 k Ω**
Coil current: * * 4.1 mA**
Response time: approximately 7 ms
Release time: approximately 3 ms
Type: Non Latched Electromagnetic Relay
2. Contact parameters (2PDT/DPDT, two sets of conversion contacts):
Contact material: AgNi silver nickel
Maximum switching voltage: * * 250 V AC/250 V DC**
Continuous rated current: * * 8 A**
Minimum switching conditions: 5 V, 10 mA
Impulse current: 25 A (20ms)
Resistance load breaking power:
24V DC：190W； 48V DC：85W； 110V DC：44W
3. Machinery and Environment:
Working temperature: * * -40 ℃~+85 ℃**
Protection level: RT III (anti cleaning)
Standards: EN 61810-1, IEC 60664
2961202 – Single relay – REL-MR-110DC
