– Required installation diameter: 230 mm
– Stroke: 80 mm
– Max extended height:135 mm, Min installation height:50 mm
– Operating pressure: 0 ~ 8 bar
– Pneumatic port: G3/4
– Medium: Compressed air, non-lubricated
– Max tilt angle:20°, Max lateral offset:10 mm
– Material: Bellows NR/BR, end caps galvanized steel
– Ambient temperature: -40 ~ +70 ℃
36488 EB-215-80 Specifications
| Required installation diameter | 230 mm |
|---|---|
| Stroke | 80 mm |
| Max extended height | 135 mm, Min installation height:50 mm |
| Operating pressure | 0 ~ 8 bar |
| Pneumatic port | G3/4 |
| Medium | Compressed air, non-lubricated |
| Max tilt angle | 20°, Max lateral offset:10 mm |
| Material | Bellows NR/BR, end caps galvanized steel |
| Ambient temperature | -40 ~ +70 ℃ |
About the 36488 EB-215-80
The 36488 EB-215-80 is a electrical products used in industrial automation, control and power systems. It is rated at Required installation diameter 230 mm, Stroke 80 mm, Max extended height 135 mm, Min installation height:50 mm. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 36488 EB-215-80 for accurate procurement and cross-referencing.
Why source the 36488 EB-215-80 from HDE123
- Verified part number: every 36488 EB-215-80 is checked against its manufacturer specification before shipment.
- 9 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 36488 EB-215-80
To order the 36488 EB-215-80, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
