-Main circuit voltage: * * 200-480V AC**
-Control power supply: * * 110-250V AC**
1. Rated working current Ie: * * 370A**
2. Suitable motor power: 230V → 110kW; 400V → 200kW
3. Wiring method: * * Screw terminals**
4. Interface: 1 analog output, 1 digital input, 3 digital outputs (2NO+1 conversion contacts)
5. Built in bypass contactor, two-phase control
6. Start ramp time: 0-20s; stop ramp time: 0-20s
7. Protection level: * * IP00 * * (up to IP20 with terminal cover)
8. Dimensions: Width 160 x Height 230 x Depth 282 mm
9. Working environment temperature: -25 ℃~+60 ℃
10. Protection functions: overload, phase loss, motor failure, thyristor protection
11. Certification: CE, UL, CSA, CCC
3RW5075-6AB14 Specifications
| Main circuit voltage | * * 200-480V AC** |
|---|---|
| Control power supply | * * 110-250V AC** |
| 1. Rated working current Ie | * * 370A** |
| 2. Suitable motor power | 230V → 110kW; 400V → 200kW |
| 3. Wiring method | * * Screw terminals** |
| 4. Interface | 1 analog output, 1 digital input, 3 digital outputs (2NO+1 conversion contacts) |
| 6. Start ramp time | 0-20s; stop ramp time: 0-20s |
| 7. Protection level | * * IP00 * * (up to IP20 with terminal cover) |
| 8. Dimensions | Width 160 x Height 230 x Depth 282 mm |
| 9. Working environment temperature | -25 ℃~+60 ℃ |
| 10. Protection functions | overload, phase loss, motor failure, thyristor protection |
| 11. Certification | CE, UL, CSA, CCC |
About the 3RW5075-6AB14
The 3RW5075-6AB14 is a electrical products used in industrial automation, control and power systems. It is rated at Main circuit voltage * * 200-480V AC**, Control power supply * * 110-250V AC**, 1. Rated working current Ie * * 370A**. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 3RW5075-6AB14 for accurate procurement and cross-referencing.
Why source the 3RW5075-6AB14 from HDE123
- Verified part number: every 3RW5075-6AB14 is checked against its manufacturer specification before shipment.
- 12 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 3RW5075-6AB14
To order the 3RW5075-6AB14, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
