Part Number: 574229
Model: VUVG-L14-M52-AT-G18-1R8L
Brand: Festo (Germany)
Product Name: 5/2-way monostable pilot solenoid valve, VUVG series
Pneumatic parameters
Valve function: 5/2 way, monostable, pneumatic return
Nominal width: 14 mm
Standard flow rate: 680～730 L/min
Working pressure: 2.5 bar ~ 8 bar
Air port thread: G1/8 for all ports
Exhaust port: Equipped with adjustable throttling silencer interface
Switch-on time: 14 ms；Switch-off time: 22 ms
Max switching frequency: 2 Hz
Electrical parameters
Rated voltage: 24 V DC (voltage tolerance ±10%)
Coil power: 1 W
Electrical connector: 3-pin M8 A-coded plug
Duty cycle: 100% continuous power supply
Environmental & material parameters
Medium: Compressed air complying with ISO 8573-1 [7:4:4]
Ambient temperature: -5 ℃ ~ +60 ℃
Protection class: IP65 (with matched plug)
Corrosion resistance grade: CRC2
Sealing material: HNBR soft seal
Certifications: CE, UL, RoHS, RCM
574229 VUVG-L14-M52-AT-G18-1R8L Specifications
| Part Number | 574229 |
|---|---|
| Model | VUVG-L14-M52-AT-G18-1R8L |
| Brand | Festo (Germany) |
| Product Name | 5/2-way monostable pilot solenoid valve, VUVG series |
| Valve function | 5/2 way, monostable, pneumatic return |
| Nominal width | 14 mm |
| Standard flow rate | 680～730 L/min |
| Working pressure | 2.5 bar ~ 8 bar |
| Air port thread | G1/8 for all ports |
| Exhaust port | Equipped with adjustable throttling silencer interface |
| Switch-on time | 14 ms；Switch-off time: 22 ms |
| Max switching frequency | 2 Hz |
| Rated voltage | 24 V DC (voltage tolerance ±10%) |
| Coil power | 1 W |
| Electrical connector | 3-pin M8 A-coded plug |
| Duty cycle | 100% continuous power supply |
| Medium | Compressed air complying with ISO 8573-1 [7:4:4] |
| Ambient temperature | -5 ℃ ~ +60 ℃ |
| Protection class | IP65 (with matched plug) |
| Corrosion resistance grade | CRC2 |
| Sealing material | HNBR soft seal |
| Certifications | CE, UL, RoHS, RCM |
About the 574229 VUVG-L14-M52-AT-G18-1R8L
The Festo (Germany) 574229 VUVG-L14-M52-AT-G18-1R8L is a electrical products used in industrial automation, control and power systems. It is rated at Part Number 574229, Model VUVG-L14-M52-AT-G18-1R8L, Brand Festo (Germany). Manufactured by Festo (Germany), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 574229 VUVG-L14-M52-AT-G18-1R8L for accurate procurement and cross-referencing.
Why source the 574229 VUVG-L14-M52-AT-G18-1R8L from HDE123
- Verified part number: every 574229 VUVG-L14-M52-AT-G18-1R8L is checked against its manufacturer specification before shipment.
- 22 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 574229 VUVG-L14-M52-AT-G18-1R8L
To order the Festo (Germany) 574229 VUVG-L14-M52-AT-G18-1R8L, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
