Channel count: 4 digital output channels (4DO)
Rated load voltage: DC 24V
Single channel rated output current: 0.5A; load range 7mA ~ 0.6A
Zero-signal residual leakage current: ≤0.5mA per channel
Built-in independent short-circuit protection & reverse polarity protection
Max switching frequency: 800Hz (resistive load), 2Hz (inductive solenoid valve load), 10Hz lamp load
Response delay: Max 50μs (0→1), max 120μs (1→0)
Backplane bus power consumption: Max 10mA @3.3V DC; typical power loss 0.8W
Max lamp load per channel: 5W
Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0 Specifications
| Channel count | 4 digital output channels (4DO) |
|---|---|
| Rated load voltage | DC 24V |
| Single channel rated output current | 0.5A; load range 7mA ~ 0.6A |
| Zero-signal residual leakage current | ≤0.5mA per channel |
| Max switching frequency | 800Hz (resistive load), 2Hz (inductive solenoid valve load), 10Hz lamp load |
| Response delay | Max 50μs (0→1), max 120μs (1→0) |
| Backplane bus power consumption | Max 10mA @3.3V DC; typical power loss 0.8W |
| Max lamp load per channel | 5W |
About the Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0
The Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0 is a electrical products used in industrial automation, control and power systems. It is rated at Channel count 4 digital output channels (4DO), Rated load voltage DC 24V, Single channel rated output current 0.5A; load range 7mA ~ 0.6A. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0 for accurate procurement and cross-referencing.
Why source the Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0 from HDE123
- Verified part number: every Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0 is checked against its manufacturer specification before shipment.
- 8 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0
To order the Standard DC24V/0.5A Digital Output Electronic Module 6ES7132-4BD02-0AA0, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
