6ES7132-6BH00-0BA0 Digital Output Module
Brand: SIEMENS (Germany)
Model: 6ES7132-6BH00-0BA0
Product Name: SIMATIC ET200SP DQ 16×24VDC/0.5A ST Digital Output Module
Specifications
Output channels: 16 digital outputs
Output type: PNP sourcing output
Rated voltage: DC 24 V
Per channel output current: 0.5 A
Maximum total module current: 8 A
Short-circuit protection: Yes
Compatible base unit: BU type A0, color code CC00
Module width: 20 mm
Cable length: Max 1000 m (shielded), max 600 m (unshielded)
Switching frequency: Max 100 Hz (resistive load); Max 2 Hz (inductive load)
Power consumption: Typ. 1 W
Operating temperature: -30 ℃ ~ +60 ℃
Protection class: IP20
6ES7132-6BH00-0BA0 Specifications
| Brand | SIEMENS (Germany) |
|---|---|
| Model | 6ES7132-6BH00-0BA0 |
| Product Name | SIMATIC ET200SP DQ 16×24VDC/0.5A ST Digital Output Module |
| Output channels | 16 digital outputs |
| Output type | PNP sourcing output |
| Rated voltage | DC 24 V |
| Per channel output current | 0.5 A |
| Maximum total module current | 8 A |
| Short-circuit protection | Yes |
| Compatible base unit | BU type A0, color code CC00 |
| Module width | 20 mm |
| Cable length | Max 1000 m (shielded), max 600 m (unshielded) |
| Switching frequency | Max 100 Hz (resistive load); Max 2 Hz (inductive load) |
| Power consumption | Typ. 1 W |
| Operating temperature | -30 ℃ ~ +60 ℃ |
| Protection class | IP20 |
About the 6ES7132-6BH00-0BA0
The SIEMENS (Germany) 6ES7132-6BH00-0BA0 is a electrical products used in industrial automation, control and power systems. It is rated at Brand SIEMENS (Germany), Model 6ES7132-6BH00-0BA0, Product Name SIMATIC ET200SP DQ 16×24VDC/0.5A ST Digital Output Module. Manufactured by SIEMENS (Germany), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 6ES7132-6BH00-0BA0 for accurate procurement and cross-referencing.
Why source the 6ES7132-6BH00-0BA0 from HDE123
- Verified part number: every 6ES7132-6BH00-0BA0 is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 6ES7132-6BH00-0BA0
To order the SIEMENS (Germany) 6ES7132-6BH00-0BA0, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
