Brand: Siemens
Model:6ES7193‑6BP20‑0DA0
Product:ET200‑SP push‑in‑type base‑unit BU15‑P16+A10+2D, BU‑type A0 spring‑terminal base with 10‑channel AUX auxiliary terminals, new independent load‑group
Compatible‑modules: All A0‑size 15‑mm‑width ET200‑SP signal‑modules and safety‑I/O modules
Wiring‑type: Screw‑free push‑in spring terminals, conductor cross‑section 0.14‑1.5mm², 16 process‑I/O terminals, 2 main power‑terminals and 10 AUX distribution‑terminals
Electrical‑spec: Rated‑voltage 24 VDC, operating‑range 20.4‑26.4 VDC; maximum 10‑amp load‑current for main‑bus and AUX‑bus, 2‑amp for single process‑terminal, 707 VDC dielectric‑test‑voltage, isolated new‑potential‑group separated from left‑side base‑unit
Mounting: DIN‑35 standard rail installation, base width 15 mm
Features: Hot‑swap of I/O‑modules, integrated shield‑ground, multi‑way auxiliary‑power‑distribution
Protection‑grade: IP20
Dimension:15mm(W) ×141mm(H) ×58mm(D)
6ES7193-6BP20-0DA0
Hde Shopping Event
Sale_coupon_15
$65.40
In stock
In stock
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
Payment Methods:
