Model 8040/11-V30-033-B
Product Name EX-PROTECTED INSTALLATION SWITCH
Explosion proof installation switch pole 2- Pole 2
Extreme rated working voltage AC690 V AC
Rated working voltage DC220 V DC
Rated working current 16 A
Breaking capacity AC-15:16A/415V; AC‑3:8A/500V
Explosion proof certification II 2 G Ex db eb IIC T6 Gb; II 2 D Ex tb IIIC T80℃ Db
Suitable for explosion-proof area Gas Zone1/2;
Dust Zone21/22
Protection level IP66 (IEC/EN60529)
The shell material is made of fiberglass reinforced polyester resin. The operating method is to rotate the handle 90 degrees and indicate the ON to OFF position. The cable is led in 1 × M25 (cable outer diameter Ø 7-17mm), and there are 2 M25 plugs reserved for the terminal block. The hard wire is 1.5-4mm ²; Multi strand soft wire: 1.5-2.5mm ², ambient temperature -20 ℃~+55 ℃ (T6), sealed NBR nitrile rubber, mechanical life ≥ 100000 on-off cycles
About the 8040/11-V30-033-B INSTALATION SWITCH
The 8040/11-V30-033-B INSTALATION SWITCH is a electrical products used in industrial automation, control and power systems. It is rated at Breaking capacity AC-15 16A/415V; AC‑3:8A/500V. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 8040/11-V30-033-B INSTALATION SWITCH for accurate procurement and cross-referencing.
Why source the 8040/11-V30-033-B INSTALATION SWITCH from HDE123
- Verified part number: every 8040/11-V30-033-B INSTALATION SWITCH is checked against its manufacturer specification before shipment.
- 1 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 8040/11-V30-033-B INSTALATION SWITCH
To order the 8040/11-V30-033-B INSTALATION SWITCH, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
