# Fireye 85UVF1A-1QD
**Phoenix II Integrated UV Flame Scanner**
>
> 8-pin Quick Disconnect version
## Electrical Specifications
– Power Supply: 24 VDC, 0.2 A
– Relay Contact Rating: Max. 2 A resistive load @ 230 VAC / 30 VDC
– Flame Relay: SPST Normally Open
– Fault Relay: SPST Normally Closed
– Analog Output: Galvanically isolated 4~20mA (flame intensity), Max load 750 Ω
– Electrical Connection: 8-pin quick-disconnect (QD), mating cable: 59-546 series
## Optical Specifications
– Detection Principle: Ultraviolet (UV) flame detection
– Spectral Range: 185 ~ 260 nm
– Viewing Angle: 80°
– Detection Distance: Up to 9 meters (30 ft)
– Built-in self-diagnosis & electronic self-check, auto flame ON/OFF threshold setting
## Environmental & Mechanical
– Ambient Temperature: -40℃ ~ +65℃ (-40℉ ~ +150℉)
– Humidity: 0 ~ 95% RH, non-condensing
– Enclosure: Die-cast aluminum, grey polyester coating
– Protection Class: IP66 / NEMA 4X
– Weight: 2.69 kg
– Purge Air: Clean dry cooling air, minimum flow rate 113 L/min (4 SCFM), max 425 L/min for severe service
## Approvals
FM, UL/cUL, CE, EAC, SIL3, Suitable for Class I Div.2 hazardous area, T4
## Accessories
– Mounting flange: 60-2692 (1″ NPT) / 60-2693 (1″ BSP); Heat insulating flange: 60-2919
– 8-pin quick-disconnect cable: 59-546-3 / 6 / 9 /12m
– 24VDC power supply: 60-2685 series
85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye Specifications
| Power Supply | 24 VDC, 0.2 A |
|---|---|
| Relay Contact Rating | Max. 2 A resistive load @ 230 VAC / 30 VDC |
| Flame Relay | SPST Normally Open |
| Fault Relay | SPST Normally Closed |
| Analog Output | Galvanically isolated 4~20mA (flame intensity), Max load 750 Ω |
| Electrical Connection | 8-pin quick-disconnect (QD), mating cable: 59-546 series |
| Detection Principle | Ultraviolet (UV) flame detection |
| Spectral Range | 185 ~ 260 nm |
| Viewing Angle | 80° |
| Detection Distance | Up to 9 meters (30 ft) |
| Ambient Temperature | -40℃ ~ +65℃ (-40℉ ~ +150℉) |
| Humidity | 0 ~ 95% RH, non-condensing |
| Enclosure | Die-cast aluminum, grey polyester coating |
| Protection Class | IP66 / NEMA 4X |
| Weight | 2.69 kg |
| Purge Air | Clean dry cooling air, minimum flow rate 113 L/min (4 SCFM), max 425 L/min for severe service |
| Mounting flange | 60-2692 (1" NPT) / 60-2693 (1" BSP); Heat insulating flange: 60-2919 |
| 8-pin quick-disconnect cable | 59-546-3 / 6 / 9 /12m |
| 24VDC power supply | 60-2685 series |
About the 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye
The 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye is a instrumentation used in industrial automation, control and power systems. It is rated at Power Supply 24 VDC, 0.2 A, Relay Contact Rating Max. 2 A resistive load @ 230 VAC / 30 VDC, Flame Relay SPST Normally Open. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye for accurate procurement and cross-referencing.
Why source the 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye from HDE123
- Verified part number: every 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye is checked against its manufacturer specification before shipment.
- 19 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye
To order the 85UVF1-1QD Plastic Housing ；85UVF1A-1QD -Fireye, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
