– P/N：**8C-PAIHA1（51454470-275）**
– Brand：Honeywell
– Type：**16-CH Analog Input Module with HART, Conformal Coated (G3)**
– System：Experion PKS / PlantCruise Series8, C300 Controller
– Matching IOTA：**8C-TAIXA1（Non-Redundant） / 8C-TAIXB1（Redundant）**
– Channels：16CH single-ended analog input
– Signal：4–20 mA, HART compatible, support 2-wire transmitter
– A/D Resolution：16 bit
– Power：24 VDC, 105 mA
– Accuracy：±0.075% FS @25℃；±0.15% FS (0~60℃)
– Scan rate：50 ms
– Isolation：1000 VAC RMS channel-to-system
– Max input voltage：±30 V
– Feature：Hot swap, HART multi-drop, open circuit detection, anti-ground loop isolation
– Weight：**Approx. 0.5 kg**
– Dimension：157 × 106 × 32 mm
8C-PAIHA1（51454470-275）
