Rating: 0.5T (equivalent to 500kg)
Accuracy Class: OIML C3
Output Signal: 3.0 mV/V (Full-scale output, tolerance ±0.0075 mV/V)
Excitation Voltage:
Rated: 5-12 VDC
Maximum: 15 VDC
Electrical Characteristics:
Input Resistance: Approx. 430±60 Ω
Output Resistance: Approx. 350±3.5 Ω
Insulation Resistance: ≥5000 MΩ
Temperature Range:
Operating Temperature: -40°C to 80°C
Compensation Temperature: -10°C to 40°C
9363-0.5T-C3-20T1
