– Main contact: 3NO, AC-3: 140A @400V, for motor up to 75kW; AC-1:200A
– Auxiliary contact: 1NO +1NC
– Coil control voltage: 100~250V AC 50/60Hz / DC wide range
– Rated insulation voltage Ui: 1000V
– Rated operational voltage Ue: 690V
– Mounting: 35mm DIN rail or panel mounting
– Terminal: Screw terminal
– Protection class: IP20 terminals
AF140-30-11 13*100-250V 50/60Hz-DC Specifications
| Main contact | 3NO, AC-3: 140A @400V, for motor up to 75kW; AC-1:200A |
|---|---|
| Auxiliary contact | 1NO +1NC |
| Coil control voltage | 100~250V AC 50/60Hz / DC wide range |
| Rated insulation voltage Ui | 1000V |
| Rated operational voltage Ue | 690V |
| Mounting | 35mm DIN rail or panel mounting |
| Terminal | Screw terminal |
| Protection class | IP20 terminals |
About the AF140-30-11 13*100-250V 50/60Hz-DC
The AF140-30-11 13*100-250V 50/60Hz-DC is a electrical products used in industrial automation, control and power systems. It is rated at Main contact 3NO, AC-3: 140A @400V, for motor up to 75kW; AC-1:200A, Auxiliary contact 1NO +1NC, Coil control voltage 100~250V AC 50/60Hz / DC wide range. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number AF140-30-11 13*100-250V 50/60Hz-DC for accurate procurement and cross-referencing.
Why source the AF140-30-11 13*100-250V 50/60Hz-DC from HDE123
- Verified part number: every AF140-30-11 13*100-250V 50/60Hz-DC is checked against its manufacturer specification before shipment.
- 8 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the AF140-30-11 13*100-250V 50/60Hz-DC
To order the AF140-30-11 13*100-250V 50/60Hz-DC, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
