1) Structural form:
Multi layer woven fiber reinforced rubber air hose (high-temperature air duct for oil fields/industrial air compressors)
Inner layer: High temperature resistant EPDM ternary ethylene propylene rubber (airtight smooth inner wall)
Enhancement layer: multi-layer high-strength polyester fiber woven layer (pressure bearing, deformation resistant)
Outer layer: weather resistant black EPDM rubber, wear-resistant and ozone aging resistant
2) Temperature performance (core):
Continuous long-term working temperature: -40 ℃ to+150 ℃
Short term instantaneous peak withstand temperature: 250 ℃ (marked as 250C on the pipe label)
Low temperature does not harden, high temperature does not bulge or delaminate, suitable for high-temperature hot air and compressed air transportation in oilfield equipment
3) Pressure parameters (industry standard for the same specifications):
Rated working pressure: 10 bar (1.0MPa)
Blasting pressure: ≥ 40 bar (safety factor 4 times)
Execution standards: GB/T 1186, EN ISO 2398 air hose standards
4) Physical characteristics:
Bending performance: Soft and rollable, with a minimum bending radius of ≥ 120mm
Media adaptation: Compressed air, hot air, inert gas, and a small amount of compressed air with oil; Resistant to weak acid and alkali, ozone, and outdoor aging
Not resistant to: strong aromatic solvents, concentrated strong acids
AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C Specifications
| Inner layer | High temperature resistant EPDM ternary ethylene propylene rubber (airtight smooth inner wall) |
|---|---|
| Enhancement layer | multi-layer high-strength polyester fiber woven layer (pressure bearing, deformation resistant) |
| Outer layer | weather resistant black EPDM rubber, wear-resistant and ozone aging resistant |
| Continuous long-term working temperature | -40 ℃ to+150 ℃ |
| Rated working pressure | 10 bar (1.0MPa) |
| Blasting pressure | ≥ 40 bar (safety factor 4 times) |
| Execution standards | GB/T 1186, EN ISO 2398 air hose standards |
| Bending performance | Soft and rollable, with a minimum bending radius of ≥ 120mm |
| Not resistant to | strong aromatic solvents, concentrated strong acids |
About the AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C
The AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C is a hydraulic & pneumatic products used in industrial automation, control and power systems. It is rated at Inner layer High temperature resistant EPDM ternary ethylene propylene rubber (airtight smooth inner wall), Enhancement layer multi-layer high-strength polyester fiber woven layer (pressure bearing, deformation resistant), Outer layer weather resistant black EPDM rubber, wear-resistant and ozone aging resistant. This hydraulic & pneumatic products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C for accurate procurement and cross-referencing.
Why source the AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C from HDE123
- Verified part number: every AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C is checked against its manufacturer specification before shipment.
- 9 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C
To order the AIRTUBE/ BLACK OD30 X ID25 30M/ROLL150C LEBELS : 250C, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
