1. Maximum flow rate: * * 2.9 LPH (liters/hour)
2. Rated output pressure: * * 8 bar (116 psi)
3. Stroke frequency: 120 times/minute
4. Power supply: * * AC220~240V, 50/60Hz * * (BL3-2 represents 220V version; BL3-1 is 110V)
5. Maximum power: about 20W
6. Material of overcurrent medium: pump head PVDF, diaphragm integrated PTFE, valve ball glass, O-ring FKM/FPM, inlet and outlet hose PE (5 × 8mm)
7. Flow regulation: Panel potentiometer 0~100% continuously adjustable
8. Status indicator: LED stroke indicator light, lit up every time the action is taken
9. Self suction height: maximum 1.5m
10. Protection level: * * IP65**
11. Shell: Fiberglass reinforced polypropylene
12. Dimensions: 194 × 165 × 121 mm
13. Environmental temperature: 0 ℃~+50 ℃, maximum relative humidity 95%, no condensation
14. Installation: Bottom plate opening, supports horizontal/wall mounted vertical installation
15. Application: Water treatment, chemical industry, electroplating, papermaking, precise addition of acid-base agents, flocculants, and scale inhibitors
BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199 Specifications
| 1. Maximum flow rate | * * 2.9 LPH (liters/hour) |
|---|---|
| 2. Rated output pressure | * * 8 bar (116 psi) |
| 3. Stroke frequency | 120 times/minute |
| 4. Power supply | * * AC220~240V, 50/60Hz * * (BL3-2 represents 220V version; BL3-1 is 110V) |
| 5. Maximum power | about 20W |
| 6. Material of overcurrent medium | pump head PVDF, diaphragm integrated PTFE, valve ball glass, O-ring FKM/FPM, inlet and outlet hose PE (5 × 8mm) |
| 7. Flow regulation | Panel potentiometer 0~100% continuously adjustable |
| 8. Status indicator | LED stroke indicator light, lit up every time the action is taken |
| 9. Self suction height | maximum 1.5m |
| 10. Protection level | * * IP65** |
| 11. Shell | Fiberglass reinforced polypropylene |
| 12. Dimensions | 194 × 165 × 121 mm |
| 13. Environmental temperature | 0 ℃~+50 ℃, maximum relative humidity 95%, no condensation |
| 14. Installation | Bottom plate opening, supports horizontal/wall mounted vertical installation |
About the BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199
The BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199 is a electrical products used in industrial automation, control and power systems. It is rated at 1. Maximum flow rate * * 2.9 LPH (liters/hour), 2. Rated output pressure * * 8 bar (116 psi), 3. Stroke frequency 120 times/minute. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199 for accurate procurement and cross-referencing.
Why source the BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199 from HDE123
- Verified part number: every BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199 is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199
To order the BLACK STONE CHEMICAL DOSING PUMP CODE: BL 3-2 S/N 1195199, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
