1. **Slot Configuration**: 12 X-bus slots (power supply occupies zero slot), XBE expansion connector for rack extension
2. **Compatibility**: BMXP34 M340 CPU, BMXCPS power supplies, all X80 analog/digital I/O modules
3. **Power Consumption**: 0.74 W typical; 86 mA @ 3.3 VDC, 30 mA @ 24 VDC
4. **Rugged Environmental Grade (H = Hardened)**:
– Operating temp: -25 °C ~ +70 °C (standard BMXXBP1200: 0 ~ 60 °C)
– Conformal coated PCB (Humiseal 1A33 TC), meets EN 60721-3-3 3C3/3C4 harsh environment
– Humidity: 10–95% RH non-condensing; IP20 cabinet protection
5. **Mounting**: DIN rail 35 mm symmetrical rail / panel plate via 4×M6 screws
6. **Certifications**: CE, UL, CSA, EAC, IACS E10 marine approved; RoHS & Green Premium compliant
X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H Specifications
| 1. **Slot Configuration | 12 X-bus slots (power supply occupies zero slot), XBE expansion connector for rack extension |
|---|---|
| 2. **Compatibility | BMXP34 M340 CPU, BMXCPS power supplies, all X80 analog/digital I/O modules |
| 3. **Power Consumption | 0.74 W typical; 86 mA @ 3.3 VDC, 30 mA @ 24 VDC |
| Operating temp | -25 °C ~ +70 °C (standard BMXXBP1200: 0 ~ 60 °C) |
| Humidity | 10–95% RH non-condensing; IP20 cabinet protection |
| 5. **Mounting | DIN rail 35 mm symmetrical rail / panel plate via 4×M6 screws |
| 6. **Certifications | CE, UL, CSA, EAC, IACS E10 marine approved; RoHS & Green Premium compliant |
About the X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H
The X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H is a electrical products used in industrial automation, control and power systems. It is rated at 1. **Slot Configuration 12 X-bus slots (power supply occupies zero slot), XBE expansion connector for rack extension, 2. **Compatibility BMXP34 M340 CPU, BMXCPS power supplies, all X80 analog/digital I/O modules, 3. **Power Consumption 0.74 W typical; 86 mA @ 3.3 VDC, 30 mA @ 24 VDC. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H for accurate procurement and cross-referencing.
Why source the X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H from HDE123
- Verified part number: every X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H is checked against its manufacturer specification before shipment.
- 7 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H
To order the X80 Ruggedized 12-Slot X-Bus Backplane BMXXBP1200H, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
