Overall circumference matching drum: 36 inch brake drum dedicated band
Band steel base width: 152 mm (6 inch); steel plate thickness: 6 mm high-strength cold rolled steel
Friction lining thickness: 12 mm high-temperature non-asbestos woven friction material, full riveted to steel band
End connection structure: Dual integrated hinged lugs with 32mm pin mounting holes for brake cylinder linkage
Single drawworks consumption: 2 pcs per complete winch brake set
Rivet layout: Uniform 42 solid steel rivets, anti-separation under heavy braking impact
Brake Band Eckel 114772 Specifications
| Overall circumference matching drum | 36 inch brake drum dedicated band |
|---|---|
| Band steel base width | 152 mm (6 inch); steel plate thickness: 6 mm high-strength cold rolled steel |
| Friction lining thickness | 12 mm high-temperature non-asbestos woven friction material, full riveted to steel band |
| End connection structure | Dual integrated hinged lugs with 32mm pin mounting holes for brake cylinder linkage |
| Single drawworks consumption | 2 pcs per complete winch brake set |
| Rivet layout | Uniform 42 solid steel rivets, anti-separation under heavy braking impact |
About the Brake Band Eckel 114772
The Brake Band Eckel 114772 is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Overall circumference matching drum 36 inch brake drum dedicated band, Band steel base width 152 mm (6 inch); steel plate thickness: 6 mm high-strength cold rolled steel, Friction lining thickness 12 mm high-temperature non-asbestos woven friction material, full riveted to steel band. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Brake Band Eckel 114772 for accurate procurement and cross-referencing.
Why source the Brake Band Eckel 114772 from HDE123
- Verified part number: every Brake Band Eckel 114772 is checked against its manufacturer specification before shipment.
- 6 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Brake Band Eckel 114772
To order the Brake Band Eckel 114772, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
