BREAKER, CIRCUIT; TYPE THERMAL-MAGNETIC TRIP, POTENTIAL 690 VAC, CURRENT 10 A, 3 ELECTRICAL POLE QUANTITY, INTERRUPT CAPACITY 100 KA, MOUNTING FACILITY DIN RAIL, TEMPERATURE RANGE -20 TO +60 DEG C, WIDTH 45 MM, LENGTH 91 MM, HEIGHT 97 MM, FREQUENCY 50/60 HZ, PHASE QUANTITY 3, STANDARD DIN EN 61346-2; BREAKER CIRCUIT 3RV2011-1JA10 “TYPE: 3RV2011-1JA10, SIRIUS, THERMAL-MAGNETIC, 4.00 KW, SIZE S00, CIRCUIT-BREAKER, STANDARD BREAKING CAPACITY. POLES: 3 PROTECTION DEGREE: IP20, FRONT END/FINGER-SAFE RATED CURENT: 7.00-10.00 AMPS @ AC-3/400 VOLTS RATED VOLTAGE: 690 VOLTS 3-AC CONTACTS: 0 NO + 0 NC AUXILIARY CIRCUIT INSULATION VOLTAGE: 690 VOLTS MAGNETIC TRIP: 130.00 AMPS TRIP CLASS: CLASS 10 RATED BREAKING CAPACITY: 100KAMPS @ 400/415 V AC, 50/60 HZ T AMBIENT: -20 TO +70°C CONNECTIONS: SCREW-TYPE TERMINAL MOUNTING: SCREW AND SNAP-ON ONTO 35 MM STANDARD RAIL. DIMENSIONS: 45X97X96(HXW XD) MM MANUFACTURER: SIEMENS” P/N: 3RV2011-1JA10 Siemens
About the BREAKER, CIRCUIT 3RV2011-1JA10
The BREAKER, CIRCUIT 3RV2011-1JA10 is a electrical products used in industrial automation, control and power systems. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number BREAKER, CIRCUIT 3RV2011-1JA10 for accurate procurement and cross-referencing.
Why source the BREAKER, CIRCUIT 3RV2011-1JA10 from HDE123
- Verified part number: every BREAKER, CIRCUIT 3RV2011-1JA10 is checked against its manufacturer specification before shipment.
- 0 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the BREAKER, CIRCUIT 3RV2011-1JA10
To order the BREAKER, CIRCUIT 3RV2011-1JA10, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
