Breathing apparatus Plus LDV A Short parel Draeger/3338967
– Backplate + harness + pneumatics (without cylinder, mask, LDV): **4.16 kg / 9.17 lb**
– Complete set (with FPS7000 mask, LDV, 6.8 L NANO carbon composite cylinder): **10.2 kg / 22.49 lb**
## English Specification
1. **Application**
Firefighting and industrial emergency rescue, self-contained open-circuit compressed air breathing apparatus.
2. **Pneumatic Performance**
– Inlet pressure: 0 … 300 bar
– Nominal 1st stage output pressure: 7.5 bar
– 1st stage maximum airflow: >1000 L/min
– Lung demand valve (LDV) output flow: >400 L/min
– Low-pressure warning whistle activation: 50–60 bar
– Whistle sound level: >90 dBA
3. **Structure & Ergonomics**
– Carbon composite backplate, aramid flame-resistant harness webbing
– Pivoting & sliding waist belt, height adjustable
– Reflective markings on backplate, shoulder and waist pads
– Integrated RFID transponder for maintenance tracking
– Machine washable harness
4. **Mechanical Gauge (Active version)**
Direct mechanical pressure indicator, no electronic PASS pre-installed; compatible for separate PASS / Bodyguard integration.
5. **Environmental Conditions**
– Operating temperature: -30 °C … +60 °C
– Storage temperature: -40 °C … +70 °C
