Model: C65H-C16
Brand: Schneider Electric
Product Name: Miniature Circuit Breaker (MCB)
Pole number: 1P
Rated current (In): 16 A
Trip curve: C curve (magnetic trip range: 5~10In)
Rated operational voltage: AC 230 V (1P), AC 400 V (multi-pole)
Rated breaking capacity (Icn): 10 kA
Rated insulation voltage (Ui): 500 V
Rated impulse withstand voltage (Uimp): 6 kV
Installation method: DIN rail mounting
Protection grade: IP20
Mechanical service life: 20000 times
Electrical service life: 10000 times
Operating temperature range: -35 ℃ ~ +70 ℃
Terminal wiring range: 1~25 mm² copper wire
C65H-C16，Schneider Specifications
| Model | C65H-C16 |
|---|---|
| Brand | Schneider Electric |
| Product Name | Miniature Circuit Breaker (MCB) |
| Pole number | 1P |
| Rated current (In) | 16 A |
| Trip curve | C curve (magnetic trip range: 5~10In) |
| Rated operational voltage | AC 230 V (1P), AC 400 V (multi-pole) |
| Rated breaking capacity (Icn) | 10 kA |
| Rated insulation voltage (Ui) | 500 V |
| Rated impulse withstand voltage (Uimp) | 6 kV |
| Installation method | DIN rail mounting |
| Protection grade | IP20 |
| Mechanical service life | 20000 times |
| Electrical service life | 10000 times |
| Operating temperature range | -35 ℃ ~ +70 ℃ |
| Terminal wiring range | 1~25 mm² copper wire |
About the C65H-C16，Schneider
The Schneider Electric C65H-C16，Schneider is a electrical products used in industrial automation, control and power systems. It is rated at Model C65H-C16, Brand Schneider Electric, Product Name Miniature Circuit Breaker (MCB). Manufactured by Schneider Electric, this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number C65H-C16，Schneider for accurate procurement and cross-referencing.
Why source the C65H-C16，Schneider from HDE123
- Verified part number: every C65H-C16，Schneider is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the C65H-C16，Schneider
To order the Schneider Electric C65H-C16，Schneider, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
