Pole number 3P thermal protection adjustment range 9-14A trip type thermal magnetic trip (overload+short circuit protection) rated working voltage Ue690V AC rated insulation voltage Ui690V AC frequency 50/60Hz usage category AC-3/AC-3e adapted motor power 5.5kW@400V Short circuit instantaneous tripping current 13 × In400V ultimate breaking capacity Icu15kA control mode button start/stop (START/STOP) terminal screw wiring terminal protection level IP20 external dimensions width 45mm × height 89mm × depth 78.2mm working temperature -20 ℃~+60 ℃
circuit breaker GV2ME16
Hde Shopping Event
Sale_coupon_15
$29.28
In stock
In stock
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
Payment Methods:
