Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1
### Model Code Decoding
– **CDM100M**: Compact Density Meter sensor, general purpose
– **A**: FOUNDATION Fieldbus communication
– **24**: DN25 (24 mm) sanitary tri-clamp process connection
– **M**: Standard pressure rating
– **B**: Integral transmitter mounted on sensor
– **A**: Local LCD display
– **G**: Standard protective coating
– **00**: No extra factory options
– **R**: Explosion-proof certification (ATEX / IECEx)
– **A**: Integrated RTD temperature sensor
– **ZZZ**: No spare parts included
– **R1**: NACE MR0175 material option for sour service (H₂S resistant)
– **TG**: ISO 17025 accredited density calibration certificate
### Measurement Performance
– Density measuring range: **0 ~ 3000 kg/m³ (0 ~ 3 g/cm³)**
– Density Accuracy: **±0.1 kg/m³ (±0.0001 g/cm³)**
– Density Repeatability: **±0.02 kg/m³ (±0.00002 g/cm³)**
– Flow velocity indication: ±5% of reading, 10:1 turndown ratio, bi-directional, max velocity 10 m/s
– Temperature measurement: 3 pcs Class B RTD sensors built-in, automatic temperature compensation
### Process Operating Conditions
– Process medium temperature: **-50 ℃ ~ +204 ℃**
– Max working pressure: **100 barg (1450 psig)** (limited by process fitting rating)
– Wetted materials: Process connection 316L SS; measuring tube Hastelloy C22 (UNS 06022)
– Sensor housing: 316L stainless steel
– Transmitter housing: Polyurethane coated aluminum alloy
– Ambient temperature: -40 ℃ ~ +65 ℃
– Protection rating: IP66 / IP67, NEMA 4X
### Communication & Certifications
– Communication: FOUNDATION Fieldbus (FF)
– Explosion protection: ATEX II2G Ex ib IIC T6, IECEx, CSA certified
– Material certification: NACE MR0175 (R1) for sour oil & gas service
– Calibration: ISO/IEC 17025 traceable multi-point density calibration (TG certificate)
– Built-in KDV health diagnostic for meter condition monitoring
– Calculable variables: Specific gravity, API gravity, mass concentration
Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1 Specifications
| CDM100M | Compact Density Meter sensor, general purpose |
|---|---|
| A | FOUNDATION Fieldbus communication |
| 24 | DN25 (24 mm) sanitary tri-clamp process connection |
| M | Standard pressure rating |
| B | Integral transmitter mounted on sensor |
| G | Standard protective coating |
| 00 | No extra factory options |
| R | Explosion-proof certification (ATEX / IECEx) |
| ZZZ | No spare parts included |
| R1 | NACE MR0175 material option for sour service (H₂S resistant) |
| TG | ISO 17025 accredited density calibration certificate |
| Density measuring range | **0 ~ 3000 kg/m³ (0 ~ 3 g/cm³)** |
| Density Accuracy | **±0.1 kg/m³ (±0.0001 g/cm³)** |
| Density Repeatability | **±0.02 kg/m³ (±0.00002 g/cm³)** |
| Flow velocity indication | ±5% of reading, 10:1 turndown ratio, bi-directional, max velocity 10 m/s |
| Temperature measurement | 3 pcs Class B RTD sensors built-in, automatic temperature compensation |
| Process medium temperature | **-50 ℃ ~ +204 ℃** |
| Max working pressure | **100 barg (1450 psig)** (limited by process fitting rating) |
| Wetted materials | Process connection 316L SS; measuring tube Hastelloy C22 (UNS 06022) |
| Sensor housing | 316L stainless steel |
| Transmitter housing | Polyurethane coated aluminum alloy |
| Ambient temperature | -40 ℃ ~ +65 ℃ |
| Protection rating | IP66 / IP67, NEMA 4X |
| Communication | FOUNDATION Fieldbus (FF) |
About the Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1
The Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1 is a instrumentation used in industrial automation, control and power systems. It is rated at CDM100M Compact Density Meter sensor, general purpose, A FOUNDATION Fieldbus communication, 24 DN25 (24 mm) sanitary tri-clamp process connection. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1 for accurate procurement and cross-referencing.
Why source the Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1 from HDE123
- Verified part number: every Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1 is checked against its manufacturer specification before shipment.
- 24 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1
To order the Densitometer Micro Motion CDM100P-A21-M-B-A-G-00-R-A-Z-Z-Z-R1, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
