– WT333E：3 input-element digital power meter
– -F：VDE power cord standard
– -C2：RS232 interface (USB is standard)
– /C7：Ethernet interface (Modbus/TCP)
– /G5：Harmonics measurement optioncdn.tmi.yo…
## Weight & Dimension
– Weight: **Approx. 5.0 kg** (main unit with above options)cdn.tmi.yo…
– Size: **213 (W) × 132 (H) × 379 (D) mm** (exclude protrusions)cdn.tmi.yo…
## Key English Specifications
– Measurement bandwidth: DC, 0.1 Hz ~ 100 kHz
– Basic power accuracy (50/60 Hz): ±0.1% of reading + ±0.05% of range
– DC accuracy: ±0.1% of reading + ±0.2% of range
– Current ranges: 0.5 A / 1 A / 2 A / 5 A /10 A /20 A (CF=3)
– Current ranges: 0.25 A /0.5 A /1 A /2.5 A /5 A /10 A (CF=6)
– Voltage ranges: 15 V / 30 V / 60 V / 100 V / 150 V / 300 V / 600 V
– Functions: Power integration, max hold, line filter, polarity separate integration, harmonics measurement (G5)
– Interface: USB (standard), RS232 (C2), Ethernet (C7, Modbus TCP)
– Update rate: Min 100 ms
– 3 input elements, support 3-phase 4-wire / 3-phase 3-wire measurementYokogawa E…
