1. Complete hydraulic technical parameters
Diameter specification: NG10 (ISO 4401-05 base plate installation, CETOP 05）
Valve core function: E-type three position four-way, center closed, fail safe center closed
Rated flow rate: 80 L/min (single throttling edge pressure difference Δ p=5bar)
Maximum working pressure: 350 bar (3X upgraded version, old 2X is 315 bar)
Allowable pressure for return oil: ≤ 100 bar
Valve core cover: SJ positive cover with damping buffer
Hydraulic medium: HLP/HL/HVLP anti-wear hydraulic oil, viscosity 10-1000 mm ²/s
Oil temperature range: -20 ℃ to+70 ℃
Sealing material: M represents NBR nitrile rubber seal
2. Electrical control parameters
Power supply: DC 24V
Given command signal: A1 interface ± 10V analog voltage command
Feedback form: Built in LVDT valve core displacement closed-loop feedback, repeat accuracy<0.5%
Drive form: OBE onboard integrated amplifier, factory calibrated zero and gain
Electrical plug: 7-pin DIN industrial plug (6-pin+PE grounded), protection level IP65
Electromagnetic compatibility: CE certification, RoHS compliance
3. Summary of Performance and Size
Dynamic characteristics: High frequency response direct acting structure, dynamic response close to servo valve level, minimal hysteresis
Installation method: Bottom plate stacked installation, no need for pilot oil supply
Approximate dimensions: length 320mm x width 140mm x height 73mm
Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1 Specifications
| Diameter specification | NG10 (ISO 4401-05 base plate installation, CETOP 05） |
|---|---|
| Valve core function | E-type three position four-way, center closed, fail safe center closed |
| Rated flow rate | 80 L/min (single throttling edge pressure difference Δ p=5bar) |
| Maximum working pressure | 350 bar (3X upgraded version, old 2X is 315 bar) |
| Allowable pressure for return oil | ≤ 100 bar |
| Valve core cover | SJ positive cover with damping buffer |
| Hydraulic medium | HLP/HL/HVLP anti-wear hydraulic oil, viscosity 10-1000 mm ²/s |
| Oil temperature range | -20 ℃ to+70 ℃ |
| Sealing material | M represents NBR nitrile rubber seal |
| Power supply | DC 24V |
| Given command signal | A1 interface ± 10V analog voltage command |
| Feedback form | Built in LVDT valve core displacement closed-loop feedback, repeat accuracy<0.5% |
| Drive form | OBE onboard integrated amplifier, factory calibrated zero and gain |
| Electrical plug | 7-pin DIN industrial plug (6-pin+PE grounded), protection level IP65 |
| Electromagnetic compatibility | CE certification, RoHS compliance |
| Dynamic characteristics | High frequency response direct acting structure, dynamic response close to servo valve level, minimal hysteresis |
| Installation method | Bottom plate stacked installation, no need for pilot oil supply |
| Approximate dimensions | length 320mm x width 140mm x height 73mm |
About the Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1
The Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1 is a hydraulic & pneumatic products used in industrial automation, control and power systems. It is rated at Diameter specification NG10 (ISO 4401-05 base plate installation, CETOP 05）, Valve core function E-type three position four-way, center closed, fail safe center closed, Rated flow rate 80 L/min (single throttling edge pressure difference Δ p=5bar). This hydraulic & pneumatic products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1 for accurate procurement and cross-referencing.
Why source the Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1 from HDE123
- Verified part number: every Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1 is checked against its manufacturer specification before shipment.
- 18 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1
To order the Direct acting high-frequency closed-loop proportional directional valve (with LVDT spool displacement feedback+OBE integrated amplification board)，R901396516 4WRPE10E80SJ-3X/M/24A1, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
