Model: EFNLQ-09-100
Brand: RENK AG (Hannover, Germany)
Type: Side flange mounted journal slide bearing (EF series)
Standard: DIN 31693 / ISO 11687-2
Size No.: 09
Shaft Diameter: 100 mm
Cooling: Natural cooling with finned housing
Lubrication: Loose oil ring self-lubrication
Bore: Cylindrical bore, non-thrust, no thrust surface
Babbitt Material: RENKmetal therm 89 white metal
Housing: Cast iron with cooling fins, side flange direct mount to motor end shield
Seal: Floating labyrinth seal (standard)
Net Weight: Approx. 62 kg
Oil Capacity: Approx. 3.3 L
Max peripheral speed for oil ring: ≤20 m/s
Optional: Pt100 temperature sensor, electric insulation, vibration sensor prep
Application: High-voltage motor, synchronous motor, fan, compressor
EFNLQ-09-100 -RENK
Hde Shopping Event
Sale_coupon_15
$2,602.99
In stock
In stock
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
