Model LHDJ-1.6 type electric contact level gauge main measuring cylinder nominal pressure 1.6 megapascals hydraulic test pressure 2.4 MPa (1.5 times nominal pressure water pressure test) working temperature PN1.6 saturated steam temperature cylinder size Φ 89 × 13 millimeters projectile material carbon steel/stainless steel (optional) electrode material high temperature resistant electrode (316 liter base) electrode quantity customization: 15/17/19/25 point electrode center distance 440/600/670 mm, customized connection form flange connection or welding connection balance pipe/lower pipe Φ 38 standard interface medium conductive liquid (deoxygenated water, boiler feedwater) matching auxiliary instrument LHDJ-19/LHDJ-25 net weight (reference) 19 point carbon steel ≈ 24 kg; 25 point carbon steel ≈ 29 kg
electric contact level gauge, LHDJ-1.6, JiLin L&H
