1. Rated voltage: 230VAC single-phase
2. Frequency: 50/60 Hz
3. Power: 50Hz: 690W; 60Hz：980W
4. Current: 50Hz: 3.10A; 60Hz：4.28A
5. Speed: 50Hz: 1340RPM; 60Hz：1410RPM
6. Impeller diameter: 280 mm
7. Dimensions: 434 × 421 × 205 mm
8. Bearing: Ball bearing
9. Supporting capacitor: 14.0 µ F/450VDB
10. Maximum air volume: 50Hz 2360 m ³/h; 60Hz 2620 m³/h
11. Static pressure: 50Hz 450Pa; 60Hz 550Pa
12. The motor is equipped with built-in thermal overload protection, insulation level F, and protection IP44
13. Purpose: High power frequency converter/industrial control cabinet cooling centrifugal fan
G4E280-BC23-05 - FAN Specifications
| 1. Rated voltage | 230VAC single-phase |
|---|---|
| 2. Frequency | 50/60 Hz |
| 3. Power | 50Hz: 690W; 60Hz：980W |
| 4. Current | 50Hz: 3.10A; 60Hz：4.28A |
| 5. Speed | 50Hz: 1340RPM; 60Hz：1410RPM |
| 6. Impeller diameter | 280 mm |
| 7. Dimensions | 434 × 421 × 205 mm |
| 8. Bearing | Ball bearing |
| 9. Supporting capacitor | 14.0 µ F/450VDB |
| 10. Maximum air volume | 50Hz 2360 m ³/h; 60Hz 2620 m³/h |
| 11. Static pressure | 50Hz 450Pa; 60Hz 550Pa |
| 13. Purpose | High power frequency converter/industrial control cabinet cooling centrifugal fan |
About the G4E280-BC23-05 - FAN
The G4E280-BC23-05 - FAN is a electrical products used in industrial automation, control and power systems. It is rated at 1. Rated voltage 230VAC single-phase, 2. Frequency 50/60 Hz, 3. Power 50Hz: 690W; 60Hz：980W. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number G4E280-BC23-05 - FAN for accurate procurement and cross-referencing.
Why source the G4E280-BC23-05 - FAN from HDE123
- Verified part number: every G4E280-BC23-05 - FAN is checked against its manufacturer specification before shipment.
- 12 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the G4E280-BC23-05 - FAN
To order the G4E280-BC23-05 - FAN, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
