GP2500-TC41-24V By  PFXGP4501TADW replace

## English Full Specifications

### General Information

– Model: PFXGP4501TADW
– Series: GP4000
– Type: 10.4″ DC powered Analog resistive touch HMI

### Display Specifications

– Display: TFT Color LCD, 10.4 inch
– Resolution: 640 × 480 pixels (VGA)
– Effective display area: W211.2 × H158.4 mm
– Colors: 65,536 colors (no blink) / 16,384 colors (blink)
– Backlight: White LED, service life ≥50,000 hrs @25°C, non-user replaceable
– Brightness: 8 adjustable levels
– Touch panel: Analog resistive film, 1024 × 1024, ≥1,000,000 touches lifecyclePro-face

### Electrical Specifications

– Rated input: 24 VDC
– Operating range: 19.2 ~ 28.8 VDC
– Max power consumption: ≤17 W
– Inrush current: ≤30 A
– Withstand voltage: 1,000 VAC, 20mA for 1 min (power terminal ↔ FG)
– Insulation resistance: ≥10 MΩ @500 VDC (power terminal ↔ FG)Pro-face

### Interfaces

– COM1: D-Sub9 RS-232C
– COM2: D-Sub9 RS-422/485
– Ethernet: 10BASE-T / 100BASE-TX
– USB-A (Host) ×1
– USB mini-B (Device) ×1
– SD Card slot: Max 32GB SD/SDHC card

### Memory

– Application memory: 16 MB
– SRAM: 128 KB
– Backup battery: Replaceable lithium battery

### Mechanical Dimensions

– External size: W315 × H241 × D56 mm
– Panel cutout: W301.5 × H227.5 mm

### Environment

– Operating temperature: 0 ~ 50 °C
– Storage temperature: -20 ~ 60 °C
– Humidity: 10~90% RH, non-condensing
– Altitude: ≤2000 m
– Pollution degree: 2
– Vibration: Compliant with IEC/EN61131-2
– Cooling: Natural convection

### Certifications

CE, UL, RoHS, ABS, DNV Marine certification
