FESTO GRLA elbow one-way exhaust flow control valve, Model GRLA-1/8-QS-6-RS-B, Mfr PN:162965, mini cylinder speed regulator for carton erector, max operating pressure 10bar
Port specification
Cylinder port: G1/8 male thread, tightening torque 3.5Nm
Tube port: QS-6 push-in fitting for OD6mm PU hose
Knurled RS adjustment knob with lock nut for anti-loose flow regulation
B fixed body, non-rotatable after installation
Flow & pressure data
Valve function: Exhaust throttling, full free flow on air supply side
Nominal throttling flow: 520 L/min @6bar
Free air flow range: 400~550 L/min
Operating pressure: 0.2~10bar
Medium & material
Medium: Clean compressed air ISO8573-1:2010 [7:4:4], lubricated & non-lubricated compatible
Glass fiber reinforced PBT body, nickel-plated aluminum thread section, brass adjusting screw, NBR seals, POM push-in clip
VDMA24364 LABS compliant & RoHS certified
Ambient & mounting
Operating temperature: -10℃ ~ +60℃
IP54 protection, universal mounting orientation
Direct screw mounting on cylinder end cap, no extra adapter needed
Application
Fine speed control for EG miniature cylinders & ADVUL small cylinders on carton erector, reduce end impact and equipment noise
FESTO GRLA-1/8-QS-6-RS-B Specifications
| Cylinder port | G1/8 male thread, tightening torque 3.5Nm |
|---|---|
| Tube port | QS-6 push-in fitting for OD6mm PU hose |
| Valve function | Exhaust throttling, full free flow on air supply side |
| Nominal throttling flow | 520 L/min @6bar |
| Free air flow range | 400~550 L/min |
| Operating pressure | 0.2~10bar |
| Medium | Clean compressed air ISO8573-1:2010 [7:4:4], lubricated & non-lubricated compatible |
| Operating temperature | -10℃ ~ +60℃ |
About the FESTO GRLA-1/8-QS-6-RS-B
The FESTO GRLA-1/8-QS-6-RS-B is a electrical products used in industrial automation, control and power systems. It is rated at Cylinder port G1/8 male thread, tightening torque 3.5Nm, Tube port QS-6 push-in fitting for OD6mm PU hose, Valve function Exhaust throttling, full free flow on air supply side. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number FESTO GRLA-1/8-QS-6-RS-B for accurate procurement and cross-referencing.
Why source the FESTO GRLA-1/8-QS-6-RS-B from HDE123
- Verified part number: every FESTO GRLA-1/8-QS-6-RS-B is checked against its manufacturer specification before shipment.
- 8 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the FESTO GRLA-1/8-QS-6-RS-B
To order the FESTO GRLA-1/8-QS-6-RS-B, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
