**Model**: SEV.65.65.22.2.50D
**Grundfos Product No**: 96047697
**Type**: Submersible Wastewater / Sewage Pump
**Impeller**: SuperVortex impeller (free passage)
**Rated shaft power P2**: 2.2 kW
**Poles**: 2-pole motor
**Power supply**: 3 × 380–415 V, 50 Hz, 3-phase
**Outlet flange**: DN65 (DIN flange)
**Max free solids passage**: 65 mm
**Performance data**:
– Rated flow: 6.75 l/s (24.3 m³/h)
– Max flow:12.5 l/s (45 m³/h)
– Rated head:10.07 m
– Max head:17.8 m
**Max operating pressure**: 6 bar
**Liquid temperature**: 0 ~ +40 °C
**pH range**: 4–10
**Max immersion depth**: 20 m
**Protection class**: IP68
**Cable**: 10 m power cable, no plug
**Material**:
– Pump housing: Cast iron EN-GJL-250
– Impeller: Cast iron
– Motor sleeve: Stainless steel
– Mechanical seal: SIC/SiC primary seal
**Installation**: Can be submerged wet-install OR dry-install (vertical / horizontal)
**Net weight**: 90 kg
**Application**: Municipal & commercial raw sewage, wastewater transport, flood control, treatment plant. Handles liquids with fibres & solid particles.
**Standard**: EN12050-1, ISO9906:2012 Class 3B2
**Explosion proof**: Non-Ex standard version
Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump Specifications
| Model | SEV.65.65.22.2.50D |
|---|---|
| Grundfos Product No | 96047697 |
| Type | Submersible Wastewater / Sewage Pump |
| Impeller | SuperVortex impeller (free passage) |
| Rated shaft power P2 | 2.2 kW |
| Poles | 2-pole motor |
| Power supply | 3 × 380–415 V, 50 Hz, 3-phase |
| Outlet flange | DN65 (DIN flange) |
| Max free solids passage | 65 mm |
| Rated flow | 6.75 l/s (24.3 m³/h) |
| Max flow | 12.5 l/s (45 m³/h) |
| Rated head | 10.07 m |
| Max head | 17.8 m |
| Max operating pressure | 6 bar |
| Liquid temperature | 0 ~ +40 °C |
| pH range | 4–10 |
| Max immersion depth | 20 m |
| Protection class | IP68 |
| Cable | 10 m power cable, no plug |
| Pump housing | Cast iron EN-GJL-250 |
| Motor sleeve | Stainless steel |
| Mechanical seal | SIC/SiC primary seal |
| Installation | Can be submerged wet-install OR dry-install (vertical / horizontal) |
| Net weight | 90 kg |
About the Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump
The Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump is a drive products used in industrial automation, control and power systems. It is rated at Model SEV.65.65.22.2.50D, Grundfos Product No 96047697, Type Submersible Wastewater / Sewage Pump. This drive products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump for accurate procurement and cross-referencing.
Why source the Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump from HDE123
- Verified part number: every Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump is checked against its manufacturer specification before shipment.
- 24 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump
To order the Grundfos SEV.65.65.22.2.50D 96047697 Sewage Pump, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
