1. Basic electrical parameters:
Model: H07RN-F 1 × 50mm ²
Rated voltage: 450/750 V
Voltage withstand test: 2500V/5min
Conductor: IEC60228 Class 5 flexible bare copper stranded wire
Maximum DC resistance of conductor at 20 ℃: ≤ 0.386 Ω/km
2. Structural specifications:
Insulation material: EPR ethylene propylene rubber, insulation thickness: 1.6 mm
Outer sheath: chloroprene rubber PCP, black, sheath thickness: 2.4 mm
Core wire color: Black (single core standard)
Cable outer diameter range: 16.5~20.6 mm
H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE Specifications
| Model | H07RN-F 1 × 50mm ² |
|---|---|
| Rated voltage | 450/750 V |
| Voltage withstand test | 2500V/5min |
| Conductor | IEC60228 Class 5 flexible bare copper stranded wire |
| Insulation material | EPR ethylene propylene rubber, insulation thickness: 1.6 mm |
| Outer sheath | chloroprene rubber PCP, black, sheath thickness: 2.4 mm |
| Core wire color | Black (single core standard) |
| Cable outer diameter range | 16.5~20.6 mm |
About the H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE
The H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE is a electrical products used in industrial automation, control and power systems. It is rated at Model H07RN-F 1 × 50mm ², Rated voltage 450/750 V, Voltage withstand test 2500V/5min. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE for accurate procurement and cross-referencing.
Why source the H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE from HDE123
- Verified part number: every H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE is checked against its manufacturer specification before shipment.
- 8 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE
To order the H07RN-F rubber cable 1×50 mm2 Type: H07RN-F MFR: ZW CABLE, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
