HEISS HBZ500-A-40/25/60-003XO Hydraulic Block Cylinder
Brand: HEISS Hydraulik + Pneumatik GmbH (Germany)
Model: HBZ500-A-40/25/60-003XO
Product Name: Compact Block Hydraulic Cylinder (Blockzylinder)
Model Code Definition
HBZ500：Series, Max working pressure 500 bar
A：Mounting form A
40：Piston diameter 40 mm
25：Piston rod diameter 25 mm
60：Stroke length 60 mm
003：Function = Double acting (standard bidirectional cylinder)
XO：Special design suffix (please confirm with supplier for exact modification)
Key Specifications
Max Operating Pressure: 500 bar
Structure: Square block compact hydraulic cylinder
Rod Surface: Hard chrome plated
Standard Seals: NBR; Viton high-temperature seal optional
Working Medium: Mineral hydraulic oil HL/HLP
Operating Temperature: -20 ℃ ~ +80 ℃ (standard)
Connection: Screw-in thread port
Mounting: Block installation type A
HBZ500-A-40/25/60-003XO Specifications
| Brand | HEISS Hydraulik + Pneumatik GmbH (Germany) |
|---|---|
| Model | HBZ500-A-40/25/60-003XO |
| Product Name | Compact Block Hydraulic Cylinder (Blockzylinder) |
| HBZ500 | Series, Max working pressure 500 bar |
| 40 | Piston diameter 40 mm |
| 25 | Piston rod diameter 25 mm |
| 60 | Stroke length 60 mm |
| 003 | Function = Double acting (standard bidirectional cylinder) |
| XO | Special design suffix (please confirm with supplier for exact modification) |
| Max Operating Pressure | 500 bar |
| Structure | Square block compact hydraulic cylinder |
| Rod Surface | Hard chrome plated |
| Standard Seals | NBR; Viton high-temperature seal optional |
| Working Medium | Mineral hydraulic oil HL/HLP |
| Operating Temperature | -20 ℃ ~ +80 ℃ (standard) |
| Connection | Screw-in thread port |
| Mounting | Block installation type A |
About the HBZ500-A-40/25/60-003XO
The HEISS Hydraulik + Pneumatik GmbH (Germany) HBZ500-A-40/25/60-003XO is a electrical products used in industrial automation, control and power systems. It is rated at Brand HEISS Hydraulik + Pneumatik GmbH (Germany), Model HBZ500-A-40/25/60-003XO, Product Name Compact Block Hydraulic Cylinder (Blockzylinder). Manufactured by HEISS Hydraulik + Pneumatik GmbH (Germany), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number HBZ500-A-40/25/60-003XO for accurate procurement and cross-referencing.
Why source the HBZ500-A-40/25/60-003XO from HDE123
- Verified part number: every HBZ500-A-40/25/60-003XO is checked against its manufacturer specification before shipment.
- 17 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the HBZ500-A-40/25/60-003XO
To order the HEISS Hydraulik + Pneumatik GmbH (Germany) HBZ500-A-40/25/60-003XO, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
