1、 Electrical parameters (IEC61984 standard)
Rated current: 16A/core (40 ℃ environment)
Rated voltage: 500V, rated impulse withstand voltage: 6kV
Contact resistance: ≤ 1m Ω (silver plated pins)
Insulation resistance: ≥ 10 ¹⁰ Ω
Wiring method: screw compression wiring
Suitable wire diameter: 1.0-2.5mm ² (AWG18-AWG14), wire stripping 7-9mm, tightening torque 0.5N · m;
2、 Structural specifications
Pin position: 4-core+PE grounding (HE-04 standard 4+1 point, a total of 5 points)
Outgoing line: TOP ENTRY top outgoing line, standard PG11 gland head, compatible with cable outer diameter of 5-10mm
Shell: Single buckle die cast aluminum shell (3A specification HE standard shell), single spring buckle quick locking
Protection: Docking lock IP65 waterproof and dustproof
Plug and unplug lifespan: ≥ 500 times;
3、 Material&Environment
Pin: Copper alloy+silver plated; Insert core: Fiberglass reinforced PA66, UL94-V0 flame retardant
Sealing ring: NBR nitrile oil resistant rubber
Working temperature: -40 ℃ to+125 ℃
Certification: CE, RoHS compliant
HDC-HE-04 connector top entry , 500V 16A Specifications
| Rated current | 16A/core (40 ℃ environment) |
|---|---|
| Rated voltage | 500V, rated impulse withstand voltage: 6kV |
| Contact resistance | ≤ 1m Ω (silver plated pins) |
| Insulation resistance | ≥ 10 ¹⁰ Ω |
| Wiring method | screw compression wiring |
| Suitable wire diameter | 1.0-2.5mm ² (AWG18-AWG14), wire stripping 7-9mm, tightening torque 0.5N · m |
| Pin position | 4-core+PE grounding (HE-04 standard 4+1 point, a total of 5 points) |
| Outgoing line | TOP ENTRY top outgoing line, standard PG11 gland head, compatible with cable outer diameter of 5-10mm |
| Shell | Single buckle die cast aluminum shell (3A specification HE standard shell), single spring buckle quick locking |
| Protection | Docking lock IP65 waterproof and dustproof |
| Plug and unplug lifespan | ≥ 500 times |
| Pin | Copper alloy+silver plated; Insert core: Fiberglass reinforced PA66, UL94-V0 flame retardant |
| Sealing ring | NBR nitrile oil resistant rubber |
| Working temperature | -40 ℃ to+125 ℃ |
| Certification | CE, RoHS compliant |
About the HDC-HE-04 connector top entry , 500V 16A
The HDC-HE-04 connector top entry , 500V 16A is a electrical products used in industrial automation, control and power systems. It is rated at Rated current 16A/core (40 ℃ environment), Rated voltage 500V, rated impulse withstand voltage: 6kV, Contact resistance ≤ 1m Ω (silver plated pins). This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number HDC-HE-04 connector top entry , 500V 16A for accurate procurement and cross-referencing.
Why source the HDC-HE-04 connector top entry , 500V 16A from HDE123
- Verified part number: every HDC-HE-04 connector top entry , 500V 16A is checked against its manufacturer specification before shipment.
- 15 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the HDC-HE-04 connector top entry , 500V 16A
To order the HDC-HE-04 connector top entry , 500V 16A, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
