1. Definition of Model Code:
S1115: 1500V High Voltage DC Contactor Series
/10: Rated heating current 1000A
1. P: Bottom plate fixed installation
33: Auxiliary contact 3NO+3NC (3 open and 3 closed)
110V: Rated voltage of coil DC110V
B: Coil reverse electromotive force varistor absorption protection module
2. Electrical core parameters:
Main contact: rated working voltage 1250VDC, rated continuous current 1000A, DC-13 usage category
Control coil: DC 110V
Auxiliary contacts: 3 normally open and 3 normally closed, auxiliary contact capacity 10A/DC110V
Arc extinguishing structure: permanent magnet extinguishes the arc chamber and is compatible with high-voltage DC interruption
Execution standards: TB/T 1333 Railway Locomotive Electrical Standard, IEC 61373 Vehicle mounted Vibration and Shock Standard
3. Physics and Environment:
Single unit weight: ≈ 12kg
Protection level: IP00
Working temperature: -40 ℃~+70 ℃
Mechanical lifespan: ≥ 1 million cycles, electrical lifespan ≥ 100000 cycles
High voltage and high-power DC contactor，S1115/10-P-33-110V-B，1250VDC，1000A
