– Sensing type: Inductive, non-flush mounting
– Sensing distance: 30 mm
– Power supply: 20~250 V AC/DC, 2-wire system
– Output function: Normally open (NO)
– Switching frequency: 25 Hz (AC), 50 Hz (DC)
– Housing: PBT plastic, cylindrical Ø34mm, length 82mm
– Connection: 2m PVC fixed cable
– Protection class: IP67
– Ambient temperature: -25℃ ~ +80℃
– Built-in reverse polarity protection
IB0026 Specifications
| Sensing type | Inductive, non-flush mounting |
|---|---|
| Sensing distance | 30 mm |
| Power supply | 20~250 V AC/DC, 2-wire system |
| Output function | Normally open (NO) |
| Switching frequency | 25 Hz (AC), 50 Hz (DC) |
| Housing | PBT plastic, cylindrical Ø34mm, length 82mm |
| Connection | 2m PVC fixed cable |
| Protection class | IP67 |
| Ambient temperature | -25℃ ~ +80℃ |
About the IB0026
The IB0026 is a electrical products used in industrial automation, control and power systems. It is rated at Sensing type Inductive, non-flush mounting, Sensing distance 30 mm, Power supply 20~250 V AC/DC, 2-wire system. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IB0026 for accurate procurement and cross-referencing.
Why source the IB0026 from HDE123
- Verified part number: every IB0026 is checked against its manufacturer specification before shipment.
- 9 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IB0026
To order the IB0026, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
