Basic Information Model: DI5020 Brand: IFM (Yifumen) Product Type: Compact Speed Monitor (Integrated Inductive Sensor+Evaluation Unit) Core Usage: Rotation/Linear Motion Underspeed Monitoring (Triggered Below Set Value), Suitable for Conveying, Packaging, Machine Tool and Other Scenarios Core Features: M30 Integrated Shell, Potentiometer Setting, Dual LED Status Indication Wiring Method: 2m Pre wired Cable
Electrical parameters Power supply voltage: 10-36 V DC current loss: ≤ 20 mA Electrical design: PNP output function: normally open (NO) switch Voltage drop: maximum 2.5 V Continuous/peak output current: 250 mA Protection: reverse phase, short circuit, overload protection Safety level: Class III
Monitoring and Performance Parameter Induction Principle: Inductive Induction Distance: 10 mm (Flat Installation) Working Distance: 0-8.1 mm Setting Range: 5-3600 Imp/min Delay: 10% Sr Start Delay: 15 s Correction Factors: Steel 1, Special Steel 0.7, Brass 0.5, Aluminum 0.4, Copper 0.3
Physical and environmental parameters: Shell: M30 × 1.5 thread, brass (special coating)+PA+TPE-U Size: M30 × 1.5, length 80 mm Weight: 282.3 g Tightening torque: 50 Nm Protection level: IP65/IP67 Operating temperature: -25 ℃ -+70 ℃ Storage temperature: -40 ℃ -+85 ℃
Certification and Compliance Certification: CE Compliance: Complies with EN 60947-5-2 and other standards
About the IFM DI5020 Yifumen brand new rotation speed sensor
The IFM DI5020 Yifumen brand new rotation speed sensor is a oil drilling equipment used in industrial automation, control and power systems. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IFM DI5020 Yifumen brand new rotation speed sensor for accurate procurement and cross-referencing.
Why source the IFM DI5020 Yifumen brand new rotation speed sensor from HDE123
- Verified part number: every IFM DI5020 Yifumen brand new rotation speed sensor is checked against its manufacturer specification before shipment.
- 0 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IFM DI5020 Yifumen brand new rotation speed sensor
To order the IFM DI5020 Yifumen brand new rotation speed sensor, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
