1. Model | IGSU14d/6D. 3-S12
2. Order number | 50126785
3. Product Type | Ultrasonic fork sensor Ultrasonic fork tag sensor
4. Detection purpose | Transparent, semi transparent, opaque label detection
5. Slot width | 4mm
6. Slot depth | 70 mm
7. Minimum label width | 10mm
8. Minimum label gap | 2mm
9. Supply voltage | 12-30 V DC, residual ripple ≤ 15%. Le
10. Maximum consumption current | 80 mA
11. Output | 2-channel push-pull transistor output Pushpull, maximum 100mA; PNP/NPN switchable eero
12. Response time | 0.2 ms; readiness delay of 300 msero
13. Input | 1-channel teaching input
14. Electrical interface | M12-5-pin male metal connector eero
15. Protection | Reverse Polarity Protection, Short Circuit Protection, Labor Easy Test Le
16. Shell material | Metal
17. Environmental temperature | -20 ℃~+60 ℃
18. Protection level | IP67
19. Maximum conveyor belt speed | 50 m/min (demonstration mode) eero
About the IGSU14d/6D.3-S12
The IGSU14d/6D.3-S12 is a electrical products used in industrial automation, control and power systems. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IGSU14d/6D.3-S12 for accurate procurement and cross-referencing.
Why source the IGSU14d/6D.3-S12 from HDE123
- Verified part number: every IGSU14d/6D.3-S12 is checked against its manufacturer specification before shipment.
- 0 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IGSU14d/6D.3-S12
To order the IGSU14d/6D.3-S12, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
