1 Electrical parameters:
Working voltage: DC 10-30 V
Output type: PNP, normally open/normally closed switchable NO/NC
Rated detection distance Sn: 4 mm
Switching frequency: 2500 Hz
Maximum output current: 200 mA
Anti short circuit: equipped with short circuit protection;
2. Mechanical parameters:
Thread specification: M12 × 1
Dimensions: Φ 12 mm x total length 70 mm
Installation method: * * Non flush installation (non flush)**
Shell material: stainless steel
Tightening torque: maximum 20 Nm
Connection method: M12-4-pin connector;
3. Environment and Protection:
Protection level: IP68
Working temperature range: -25 ℃~+70 ℃
Equipped with LED status indicator light.
Inductive proximity sensor，BES 516-131-S4-C Specifications
| Working voltage | DC 10-30 V |
|---|---|
| Output type | PNP, normally open/normally closed switchable NO/NC |
| Rated detection distance Sn | 4 mm |
| Switching frequency | 2500 Hz |
| Maximum output current | 200 mA |
| Anti short circuit | equipped with short circuit protection |
| Thread specification | M12 × 1 |
| Dimensions | Φ 12 mm x total length 70 mm |
| Installation method | * * Non flush installation (non flush)** |
| Shell material | stainless steel |
| Tightening torque | maximum 20 Nm |
| Connection method | M12-4-pin connector |
| Protection level | IP68 |
| Working temperature range | -25 ℃~+70 ℃ |
About the Inductive proximity sensor，BES 516-131-S4-C
The Inductive proximity sensor，BES 516-131-S4-C is a electrical products used in industrial automation, control and power systems. It is rated at Working voltage DC 10-30 V, Output type PNP, normally open/normally closed switchable NO/NC, Rated detection distance Sn 4 mm. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Inductive proximity sensor，BES 516-131-S4-C for accurate procurement and cross-referencing.
Why source the Inductive proximity sensor，BES 516-131-S4-C from HDE123
- Verified part number: every Inductive proximity sensor，BES 516-131-S4-C is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Inductive proximity sensor，BES 516-131-S4-C
To order the Inductive proximity sensor，BES 516-131-S4-C, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
