1. Model: NJ15-30GK-N
2. Brand: Pepperl+Fuchs (P+F)
3. Type: Inductive proximity sensor/NAMUR explosion-proof proximity switch
4. Rated detection distance Sn: 15 mm
5. Reliable operating distance Sa: 0-12.15 mm
6. Installation method: Non flush (non shielded)
7. Output format: NAMUR two-wire system, normally closed NC
8. Rated voltage Uo: 8.2 V DC (internal resistance about 1k Ω)
9. Switching frequency: 0-100 Hz
10. Delay: Typical 3% (1-5%)
11. Current: Metal free ≥ 3 mA; Metal induced ≤ 1 mA
12. Attenuation coefficient: Aluminum 0.4/Copper 0.3/Stainless steel 304:0.85
13. Thread specification: M30 × 1.5
14. Material of shell/sensing surface: PBT engineering plastic
15. Outgoing line: 2 m PVC cable, core 0.75 mm ²
16 Protection level: IP68
17. Working environment temperature: -25 ℃~+100 ℃
18. Explosion proof rating: 2G; 1D, can be used in hazardous areas, supports SIL2 (IEC61508)
19. Execution standards: IEC/EN 60947-5-2, EN 60947-5-6 (NAMUR standard)
Inductive proximity sensor，NJ15-30GK-N Specifications
| 1. Model | NJ15-30GK-N |
|---|---|
| 2. Brand | Pepperl+Fuchs (P+F) |
| 3. Type | Inductive proximity sensor/NAMUR explosion-proof proximity switch |
| 4. Rated detection distance Sn | 15 mm |
| 5. Reliable operating distance Sa | 0-12.15 mm |
| 6. Installation method | Non flush (non shielded) |
| 7. Output format | NAMUR two-wire system, normally closed NC |
| 8. Rated voltage Uo | 8.2 V DC (internal resistance about 1k Ω) |
| 9. Switching frequency | 0-100 Hz |
| 10. Delay | Typical 3% (1-5%) |
| 11. Current | Metal free ≥ 3 mA; Metal induced ≤ 1 mA |
| 12. Attenuation coefficient | Aluminum 0.4/Copper 0.3/Stainless steel 304:0.85 |
| 13. Thread specification | M30 × 1.5 |
| 14. Material of shell/sensing surface | PBT engineering plastic |
| 15. Outgoing line | 2 m PVC cable, core 0.75 mm ² |
| 16 Protection level | IP68 |
| 17. Working environment temperature | -25 ℃~+100 ℃ |
| 18. Explosion proof rating | 2G; 1D, can be used in hazardous areas, supports SIL2 (IEC61508) |
| 19. Execution standards | IEC/EN 60947-5-2, EN 60947-5-6 (NAMUR standard) |
About the Inductive proximity sensor，NJ15-30GK-N
The Inductive proximity sensor，NJ15-30GK-N is a electrical products used in industrial automation, control and power systems. It is rated at 1. Model NJ15-30GK-N, 2. Brand Pepperl+Fuchs (P+F), 3. Type Inductive proximity sensor/NAMUR explosion-proof proximity switch. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Inductive proximity sensor，NJ15-30GK-N for accurate procurement and cross-referencing.
Why source the Inductive proximity sensor，NJ15-30GK-N from HDE123
- Verified part number: every Inductive proximity sensor，NJ15-30GK-N is checked against its manufacturer specification before shipment.
- 19 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Inductive proximity sensor，NJ15-30GK-N
To order the Inductive proximity sensor，NJ15-30GK-N, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
