1. Electrical parameters:
Control coil voltage: * * 20-26 VDC (rated 24 VDC)
Number of channels: * * 8 SPDT single pole double throw relay outputs
Contact capacity of each relay:
Resistive load: 120 VAC/24 VDC, * * 6 A
Maximum thermoelectric current Ith: 10 A
Coil current per circuit: 2 mA (indicator light circuit) Rockwell
Input interface: 20 pin IDC flat cable, compatible with PLC digital output
On site side: screw terminal, fixed terminal block (non removable RTB)
Each channel is equipped with LED status indicator lights
2. Machinery and Environment:
Installation method: DIN 35mm rail installation
Shell size: 160mm x 83mm x 70.5mm (W x H x D)
Working environment temperature: -20 ° C to+60 ° C
Certification: UL/c-ULus, CE
Reference manuals: 1492-TD008, 1492-UM001 Rockwell A
INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T Specifications
| Control coil voltage | * * 20-26 VDC (rated 24 VDC) |
|---|---|
| Number of channels | * * 8 SPDT single pole double throw relay outputs |
| Resistive load | 120 VAC/24 VDC, * * 6 A |
| Maximum thermoelectric current Ith | 10 A |
| Coil current per circuit | 2 mA (indicator light circuit) Rockwell |
| Input interface | 20 pin IDC flat cable, compatible with PLC digital output |
| On site side | screw terminal, fixed terminal block (non removable RTB) |
| Installation method | DIN 35mm rail installation |
| Shell size | 160mm x 83mm x 70.5mm (W x H x D) |
| Working environment temperature | -20 ° C to+60 ° C |
| Certification | UL/c-ULus, CE |
| Reference manuals | 1492-TD008, 1492-UM001 Rockwell A |
About the INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T
The INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T is a electrical products used in industrial automation, control and power systems. It is rated at Control coil voltage * * 20-26 VDC (rated 24 VDC), Number of channels * * 8 SPDT single pole double throw relay outputs, Resistive load 120 VAC/24 VDC, * * 6 A. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T for accurate procurement and cross-referencing.
Why source the INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T from HDE123
- Verified part number: every INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T is checked against its manufacturer specification before shipment.
- 12 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T
To order the INTERFACE MODULE 1492-XIM2024-8RStandard Bulletin Style 802T, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
