Model Definition：13=130 frame size; H=high inertia; 23=2.3kW; C15=1500rpm; 4=400V class; P9=23-bit absolute encoder; A=standard configuration
Rated Power：2.3kW
Matched Drive：INVT DA200 series (e.g., 2kW class models like SV-DA200-2R0-4-C0)
Input Power： 3P AC 380V(-15%)~440V(+10%), 47~63Hz
Rated Speed：1500rpm
Max Speed：4500rpm
Rated Current Approx：7.7A (subject to official manual)
Rated Torque：14.9Nm
Peak Torque： 44.7Nm (3 times the rated torque, lasting for 3 seconds)
Encoder：23-bit absolute encoder (P9)
IP Rating IP67 (shaft extension seal), IP20 (terminal box)
Cooling Method：Self-cooling
INVT:IMS20B-13H23C15C-4-P9-A Specifications
| Rated Power | 2.3kW |
|---|---|
| Matched Drive | INVT DA200 series (e.g., 2kW class models like SV-DA200-2R0-4-C0) |
| Input Power | 3P AC 380V(-15%)~440V(+10%), 47~63Hz |
| Rated Speed | 1500rpm |
| Max Speed | 4500rpm |
| Rated Current Approx | 7.7A (subject to official manual) |
| Rated Torque | 14.9Nm |
| Peak Torque | 44.7Nm (3 times the rated torque, lasting for 3 seconds) |
| Encoder | 23-bit absolute encoder (P9) |
| Cooling Method | Self-cooling |
About the INVT:IMS20B-13H23C15C-4-P9-A
The INVT:IMS20B-13H23C15C-4-P9-A is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Rated Power 2.3kW, Matched Drive INVT DA200 series (e.g., 2kW class models like SV-DA200-2R0-4-C0), Input Power 3P AC 380V(-15%)~440V(+10%), 47~63Hz. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number INVT:IMS20B-13H23C15C-4-P9-A for accurate procurement and cross-referencing.
Why source the INVT:IMS20B-13H23C15C-4-P9-A from HDE123
- Verified part number: every INVT:IMS20B-13H23C15C-4-P9-A is checked against its manufacturer specification before shipment.
- 10 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the INVT:IMS20B-13H23C15C-4-P9-A
To order the INVT:IMS20B-13H23C15C-4-P9-A, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
