– Model: JOLD-45-CPXF-1L
– Brand: Jenoptik
– Type: Fiber-coupled continuous wave diode laser module
– Center Wavelength: 808 nm @25℃
– Max Optical Output Power: 45 W (CW)
– Fiber: 400 μm core, NA 0.22, SMA905 connector
– Operation Mode: CW continuous wave
– Typical operating current: 59 A
– Max operating current: 65 A
– Threshold current: 10 A (typical)
– Spectral bandwidth FWHM: 3 nm typical
– Cooling: Passive cooling, integrated TEC
– Built-in: Power monitor
– Expected lifetime: >20,000 hours
– **Net Weight: approx. 0.32 kg**
– Application: DPSS / fiber laser pumping, medical laser, material processing
JOLD-45-CPXF-1L 808nm
Hde Shopping Event
Sale_coupon_15
$3,741.79
8-12weeks
8-12weeks
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
Payment Methods:
