– Power supply: 24VDC, range 19.2~31.2VDC
– Max current consumption: 450mA
– Communication: Dual redundant BNC ControlNet ports, baud rate 5Mbps
– Max supported I/O modules: 8 sets of Flex I/O modules
– Flexbus output current: Max 640mA @5VDC
– Isolation voltage: 850VDC
– Status indicators: Comm A / Comm B / I/O status LED
– Mounting: DIN rail mounting
– Protection class: IP20
P/N#1794-ACNR15 Specifications
| Power supply | 24VDC, range 19.2~31.2VDC |
|---|---|
| Max current consumption | 450mA |
| Communication | Dual redundant BNC ControlNet ports, baud rate 5Mbps |
| Max supported I/O modules | 8 sets of Flex I/O modules |
| Flexbus output current | Max 640mA @5VDC |
| Isolation voltage | 850VDC |
| Status indicators | Comm A / Comm B / I/O status LED |
| Mounting | DIN rail mounting |
| Protection class | IP20 |
About the P/N#1794-ACNR15
The P/N#1794-ACNR15 is a electrical products used in industrial automation, control and power systems. It is rated at Power supply 24VDC, range 19.2~31.2VDC, Max current consumption 450mA, Communication Dual redundant BNC ControlNet ports, baud rate 5Mbps. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number P/N#1794-ACNR15 for accurate procurement and cross-referencing.
Why source the P/N#1794-ACNR15 from HDE123
- Verified part number: every P/N#1794-ACNR15 is checked against its manufacturer specification before shipment.
- 9 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the P/N#1794-ACNR15
To order the P/N#1794-ACNR15, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
