Model: LCK-3/8-PK-6
Brand: Festo (Germany)
Product Name: L-type male thread barbed elbow fitting
Pneumatic parameters
Thread specification: G3/8 male thread
Applicable tube: Inner diameter 6 mm hose
Nominal flow bore: 4.9 mm
Working pressure range: -0.95 ~ 10 bar
Recommended tightening torque: 12.5 Nm (±20%)
Structure: Barb type pipe connection with lock nut
Material & environmental parameters
Main body: Die-cast zinc alloy; Nut: Anodized aluminum alloy; Seal ring: PU elastomer
Working medium: Compressed air conforming to ISO 8573-1
Operating temperature: -10 ℃ ~ +60 ℃
Corrosion grade: CRC1
Certifications: RoHS, LABS-free
Installation feature
Omnidirectional installation, widely used for pipeline turning connection of cylinders, pressure reducing valves and other pneumatic components
LCK-3/8-PK-6， Festo (Germany) Specifications
| Model | LCK-3/8-PK-6 |
|---|---|
| Brand | Festo (Germany) |
| Product Name | L-type male thread barbed elbow fitting |
| Thread specification | G3/8 male thread |
| Applicable tube | Inner diameter 6 mm hose |
| Nominal flow bore | 4.9 mm |
| Working pressure range | -0.95 ~ 10 bar |
| Recommended tightening torque | 12.5 Nm (±20%) |
| Structure | Barb type pipe connection with lock nut |
| Main body | Die-cast zinc alloy; Nut: Anodized aluminum alloy; Seal ring: PU elastomer |
| Working medium | Compressed air conforming to ISO 8573-1 |
| Operating temperature | -10 ℃ ~ +60 ℃ |
| Corrosion grade | CRC1 |
| Certifications | RoHS, LABS-free |
About the LCK-3/8-PK-6， Festo (Germany)
The Festo (Germany) LCK-3/8-PK-6， Festo (Germany) is a electrical products used in industrial automation, control and power systems. It is rated at Model LCK-3/8-PK-6, Brand Festo (Germany), Product Name L-type male thread barbed elbow fitting. Manufactured by Festo (Germany), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number LCK-3/8-PK-6， Festo (Germany) for accurate procurement and cross-referencing.
Why source the LCK-3/8-PK-6， Festo (Germany) from HDE123
- Verified part number: every LCK-3/8-PK-6， Festo (Germany) is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the LCK-3/8-PK-6， Festo (Germany)
To order the Festo (Germany) LCK-3/8-PK-6， Festo (Germany), add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
