1. Electrical parameters:
Input voltage: * * AC 85-265V * * (wide voltage)
Frequency: * * 60Hz (compatible with 50Hz)**
Light source: LED, single 20W, 2, * * Total 40W**
Power factor: ≥ 0.9
Driver: Constant current driver, built-in overvoltage and short-circuit protection
2. Protection&Explosion proof:
Protection level: * * IP65 * * (dustproof, anti spray water)
Explosion proof mark (GBYL standard of the same type): * * Ex d Ⅱ B T6 Gb**
Anti corrosion grade: WF1/WF2 (conventional WF2)
Applicable hazardous areas: Zone 1 and Zone 2 for explosive gases; Dust Zone 21 and 22
3. Structure and Material:
Shell: Die cast aluminum alloy, electrostatic spray coating
Transparent cover: tempered glass/PC impact resistant lampshade
Introduction thread: G1/2 “or G3/4”, compatible with cable diameter of 6~10mm
Installation methods: suspension rod type, ceiling mounted, wall mounted
-Color temperature: 4000K (neutral white, optional 3000K/6000K)
-Color rendering index Ra>80
-Light efficiency: 90-100 lm/W
-Environmental temperature: -20 ℃~+50 ℃
-LED lifespan: ≥ 50000 hours
LED EXPLOSION PROOF LIGHTING FIXTURE, GBYL-2X2OW，IP65, 60HZ,85-265V Specifications
| Input voltage | * * AC 85-265V * * (wide voltage) |
|---|---|
| Frequency | * * 60Hz (compatible with 50Hz)** |
| Light source | LED, single 20W, 2, * * Total 40W** |
| Power factor | ≥ 0.9 |
| Driver | Constant current driver, built-in overvoltage and short-circuit protection |
| Protection level | * * IP65 * * (dustproof, anti spray water) |
| Anti corrosion grade | WF1/WF2 (conventional WF2) |
| Applicable hazardous areas | Zone 1 and Zone 2 for explosive gases; Dust Zone 21 and 22 |
| Shell | Die cast aluminum alloy, electrostatic spray coating |
| Transparent cover | tempered glass/PC impact resistant lampshade |
| Introduction thread | G1/2 "or G3/4", compatible with cable diameter of 6~10mm |
| Installation methods | suspension rod type, ceiling mounted, wall mounted |
| Color temperature | 4000K (neutral white, optional 3000K/6000K) |
| Light efficiency | 90-100 lm/W |
| Environmental temperature | -20 ℃~+50 ℃ |
| LED lifespan | ≥ 50000 hours |
About the LED EXPLOSION PROOF LIGHTING FIXTURE, GBYL-2X2OW，IP65, 60HZ,85-265V
The LED EXPLOSION PROOF LIGHTING FIXTURE, GBYL-2X2OW，IP65, 60HZ,85-265V is a instrumentation used in industrial automation, control and power systems. It is rated at Input voltage * * AC 85-265V * * (wide voltage), Frequency * * 60Hz (compatible with 50Hz)**, Light source LED, single 20W, 2, * * Total 40W**. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number LED EXPLOSION PROOF LIGHTING FIXTURE, GBYL-2X2OW，IP65, 60HZ,85-265V for accurate procurement and cross-referencing.
