lectrical Parameters
Rated Insulation Voltage: 400V AC
Conventional Thermal Current: 6A
Rated Operating Voltage: 240V AC
Utilization Category: AC-15, Ue=240V, Ie=1.5A
Short-Circuit Protection Device: 6A gg fuse
Mechanical Parameters
Housing Material: Die-cast aluminum
Cover Material: Aluminum
Actuator Type: Lever (sheet metal), roller (thermoplastic)
Operating Ambient Temperature: -30°C to +80°C
Mechanical Service Life: 1×10⁵ operating cycles, ≤100 cycles/min
Mounting Method: 2×M4
Connection Method: 4 screw connections (M3)
Conductor Cross-Section: Solid: 0.5-1.5mm²; or stranded wire with wire lug: 0.5-1.5mm²
Cable Entry: 1×M20×1.5
Weight: Approx. 0.17kg
Protection Class: IP65
Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408 Specifications
| Rated Insulation Voltage | 400V AC |
|---|---|
| Conventional Thermal Current | 6A |
| Rated Operating Voltage | 240V AC |
| Utilization Category | AC-15, Ue=240V, Ie=1.5A |
| Short-Circuit Protection Device | 6A gg fuse |
| Housing Material | Die-cast aluminum |
| Cover Material | Aluminum |
| Actuator Type | Lever (sheet metal), roller (thermoplastic) |
| Operating Ambient Temperature | -30°C to +80°C |
| Mechanical Service Life | 1×10⁵ operating cycles, ≤100 cycles/min |
| Mounting Method | 2×M4 |
| Connection Method | 4 screw connections (M3) |
| Conductor Cross-Section | Solid: 0.5-1.5mm²; or stranded wire with wire lug: 0.5-1.5mm² |
| Cable Entry | 1×M20×1.5 |
| Weight | Approx. 0.17kg |
| Protection Class | IP65 |
About the Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408
The Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408 is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Rated Insulation Voltage 400V AC, Conventional Thermal Current 6A, Rated Operating Voltage 240V AC. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408 for accurate procurement and cross-referencing.
Why source the Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408 from HDE123
- Verified part number: every Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408 is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408
To order the Limit Switch, Brand: Bernstein, Model: GC-A2Z O.BETG Article No.: 602.1800.408, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
