Inner bore diameter: 6.5 inch (165.1 mm), matched with 6 1/2” HNBR piston for HHF-1600HL pump
Outer barrel diameter: φ206 mm; overall effective axial length: 430 mm
Structure: Integral centrifugal casting bi-metal liner, double annular sealing grooves on outer wall for liner O-ring static sealing; thickened positioning shoulder for interference installation
Single pump consumption: 3 pieces per complete HHF-1600HL triplex mud pump set
Pump matching core data: Rated stroke 305 mm (12″), max stroke frequency 120 SPM, max rated discharge pressure 34.5 MPa (5000 PSI)
Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL Specifications
| Inner bore diameter | 6.5 inch (165.1 mm), matched with 6 1/2” HNBR piston for HHF-1600HL pump |
|---|---|
| Outer barrel diameter | φ206 mm; overall effective axial length: 430 mm |
| Single pump consumption | 3 pieces per complete HHF-1600HL triplex mud pump set |
| Pump matching core data | Rated stroke 305 mm (12"), max stroke frequency 120 SPM, max rated discharge pressure 34.5 MPa (5000 PSI) |
About the Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL
The Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Inner bore diameter 6.5 inch (165.1 mm), matched with 6 1/2” HNBR piston for HHF-1600HL pump, Outer barrel diameter φ206 mm; overall effective axial length: 430 mm, Single pump consumption 3 pieces per complete HHF-1600HL triplex mud pump set. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL for accurate procurement and cross-referencing.
Why source the Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL from HDE123
- Verified part number: every Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL is checked against its manufacturer specification before shipment.
- 4 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL
To order the Liner 6 1/2” HTNB140.04.01.00 for pump HHF-1600HL, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
