1. Flow pressure performance:
Nominal displacement: 10 mL/r
Rated speed: 1450 r/min (4-stage motor)
Theoretical flow rate: 14.5 L/min
Maximum continuous working pressure: 25 bar (2.5MPa)
Built in overflow valve opening pressure: 16 bar (adjustable)
Short term peak pressure: 30 bar
2. Medium and viscosity:
Applicable media: hydraulic oil, gearbox lubricating oil, turbine oil, diesel and other clean fluids
Allowable kinematic viscosity: 1.2~20000 mm ²/s (cst)
Sealing material: standard NBR nitrile rubber, optional FKM fluororubber
3. Installation and Interface:
Installation method: flange horizontal installation
Oil outlet specification: G1/4 “pipe thread for inlet and outlet
Drive shaft: flat key shaft, standard motor direct connection/coupling drive
Pump body material: cast iron shell, wear-resistant alloy steel gear
4. Working conditions and lifespan:
Allowable oil temperature: -20 ℃~+80 ℃
Allowable oil suction vacuum degree: ≤ 0.05MPa
Continuous working system S1, low noise, high volumetric efficiency
Low pressure transmission gear pump，D-58791,KF 10 RF1
