1、 Core torque and power parameters:
Drive square head: 1/2 “inch square head, friction ring sleeve locking structure
Maximum tightening torque: 1356 N · m
Nut breaking and dismantling torque: 1898 N · m
Maximum compatible bolt: M33 high-strength bolt
Four speed idle speed: 550/1400/1750/1750 rpm
Four level impact frequency: 950/1750/2100/2100 ipm
Fourth gear dedicated bolt removal mode: automatic deceleration after high torque impact to prevent bolt from swinging out
2、 Electrical configuration:
Rated voltage: DC 18V REDLITHIUM red lithium battery platform
Battery specifications: 2 M18 B5 5.0Ah lithium batteries
Charging time: A single battery can be quickly charged in about 59 minutes to fully charge
Motor: FUEL brushless permanent magnet motor, RED LINK PLUS intelligent overload protection
Lighting: Front high brightness LED work light
3、 Protection and characteristics:
Industrial grade impact resistant shell, rubber anti slip fully wrapped handle
Four speed torque and speed adjustable, no burning under heavy load
Compatible with all M18 series lithium battery packs
Standard configuration: Host x 1, 5.0Ah battery x 2, M12/M18 charger x 1, hard tool storage box
M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X Specifications
| Drive square head | 1/2 "inch square head, friction ring sleeve locking structure |
|---|---|
| Maximum tightening torque | 1356 N · m |
| Nut breaking and dismantling torque | 1898 N · m |
| Maximum compatible bolt | M33 high-strength bolt |
| Four speed idle speed | 550/1400/1750/1750 rpm |
| Four level impact frequency | 950/1750/2100/2100 ipm |
| Fourth gear dedicated bolt removal mode | automatic deceleration after high torque impact to prevent bolt from swinging out |
| Rated voltage | DC 18V REDLITHIUM red lithium battery platform |
| Battery specifications | 2 M18 B5 5.0Ah lithium batteries |
| Charging time | A single battery can be quickly charged in about 59 minutes to fully charge |
| Motor | FUEL brushless permanent magnet motor, RED LINK PLUS intelligent overload protection |
| Lighting | Front high brightness LED work light |
| Standard configuration | Host x 1, 5.0Ah battery x 2, M12/M18 charger x 1, hard tool storage box |
About the M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X
The M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Drive square head 1/2 "inch square head, friction ring sleeve locking structure, Maximum tightening torque 1356 N · m, Nut breaking and dismantling torque 1898 N · m. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X for accurate procurement and cross-referencing.
Why source the M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X from HDE123
- Verified part number: every M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X is checked against its manufacturer specification before shipment.
- 13 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X
To order the M18 FUEL High Torque 1/2" Friction Ring Impact Wrench 5.0Ah 2-Battery Kit，M18 FHIWF12-502X, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
